Jotul J-100 Replacement Ceramic Glass Panels – 20 1/4" x 12"

$165.80

Jotul J-100 Ceramic Replacement Glass

If the glass on your Jotul J-100 wood stove is cracked, damaged, or too cloudy to enjoy the flames, this replacement ceramic panel can help bring back that clear fire view.

The rectangular panel measures 20 1/4" x 12" and is 3/16" (5mm) thick. It's made from high-temperature pyro-ceramic glass rated for temperatures up to 1400°F (760°C), with the subtle amber tint commonly found in ceramic stove glass.

Replacement reference 4775106-18in is listed for the Jotul J-100. The supplied information also identifies this glass as Made in USA, with the tape gasket sold separately.

Before ordering, I'd compare your existing glass dimensions and verify the correct replacement part number. One detail I'd check carefully is the "-18in" suffix in the supplied reference, since the listed panel measures 20 1/4" wide.

Product Details / Specifications:

  • Listed Part Reference: 4775106-18in

  • Dimensions: 20 1/4" W x 12" H

  • Thickness: 3/16" (5mm)

  • Glass Type: High-temperature pyro-ceramic glass

  • Material Reference: Pyroceram / Robax equivalent (supplier-listed)

  • Temperature Rating: Up to 1400°F (760°C)

  • Shape: Rectangle

  • Tint: Clear with natural amber tint

  • Listed Compatibility: Jotul J-100

  • Tape Gasket: Sold separately

  • Made in USA

FAQs:

Q: What size is the Jotul J-100 replacement glass?
A: The supplied dimensions are 20 1/4" wide x 12" high with a thickness of 3/16" (5mm).

Q: What replacement part number is listed?
A: The supplied reference is 4775106-18in. Its status as an official Jotul manufacturer part number has not been confirmed.

Q: Is the glass gasket included?
A: No. The supplied product information states that the tape gasket is sold separately.

Q: Is this ceramic or tempered glass?
A: This panel is listed as high-temperature pyro-ceramic glass rated up to 1400°F (760°C), not standard tempered glass.

Fit / Measuring / Safety Notes:

  • Confirm your stove is a Jotul J-100.

  • Verify the official replacement part number against your stove documentation.

  • Measure carefully and confirm your required panel is 20 1/4" x 12" x 3/16".

  • Check model and production-year variations before assuming compatibility.

  • Confirm the rectangular shape and edge details against your original glass.

  • Use only the glass material and gasket specified by Jotul.

  • Never force, grind, trim, or modify ceramic glass to make it fit.

  • The supplied instructions mention a 1/8" expansion gap, but follow your specific Jotul manual rather than assuming that measurement applies.

  • Do not overtighten glass retainers or operate the stove with cracked or improperly installed glass.

Custom Glass Option:

Need a different size or have a hard-to-find Jotul glass panel? I also offer custom-cut ceramic and tempered glass to match your measurements.

Custom-Cut Ceramic & Tempered Glass

Shipping Details:

Free Shipping: 3-5 business days
