Arrow 1800 Ceramic Replacement Stove Glass – Part 1138
If the glass on your Arrow 1800 wood stove is cracked, damaged, or too cloudy to enjoy the fire, this replacement ceramic glass panel can bring that clear view back.
The rectangular panel measures 11 11/16" wide x 8 1/4" high and is 3/16" (5mm) thick. It's made from high-temperature ceramic glass rated for temperatures up to 1400°F (760°C). This is ceramic stove glass, not standard tempered glass.
Listed as replacement part 1138, this panel is compatible with select Arrow 1600 and Arrow 1800 wood stoves.
Here's where measuring really matters: another Arrow 1800 replacement glass we've worked with is listed under a different part number and size. Before ordering this panel, confirm part number 1138 and compare the dimensions with your existing glass. Same stove name doesn't always mean same piece of glass.
Product Details / Specifications:
Part Number: 1138
Dimensions: 11 11/16" W x 8 1/4" H
Thickness: 3/16" (5mm)
Glass Type: High-temperature ceramic stove glass
Temperature Rating: Up to 1400°F (760°C)
Shape: Rectangle
Tint: Clear with natural light amber tint
Compatibility: Arrow 1600 and Arrow 1800 wood stoves
Made in USA
FAQs:
Q: What size is this Arrow 1800 replacement glass?
A: This replacement panel measures 11 11/16" wide x 8 1/4" high and is 3/16" (5mm) thick.
Q: What is the replacement glass part number?
A: The supplied part number for this ceramic stove glass is 1138.
Q: Will this fit every Arrow 1800 wood stove?
A: Do not assume it will. Arrow 1800 replacement glass may vary by stove version. Confirm part number 1138 and the 11 11/16" x 8 1/4" dimensions before ordering.
Q: Does this glass also fit the Arrow 1600?
A: The supplied compatibility lists both Arrow 1600 and Arrow 1800 wood stoves. Confirm your stove version, part number, and measurements before ordering.
Fit / Measuring / Safety Notes:
Verify your exact Arrow 1600 or 1800 stove version before ordering.
Confirm part number 1138 against your stove or existing glass information.
Compare the 11 11/16" x 8 1/4" dimensions and 3/16" thickness with your existing panel.
Do not order by stove model name alone because Arrow 1800 glass sizes may vary.
Never force, grind, or trim ceramic glass to make it fit.
Do not overtighten glass retainers or mounting hardware.
Use the proper gasket and follow the stove manufacturer's glass installation instructions.
Custom Glass Option:
Need a different size or have a hard-to-find stove glass panel? Custom-cut ceramic and tempered glass is also available.
Custom-Cut Ceramic & Tempered Glass
Shipping Details:
Free Shipping: 3-5 business days
